Description
This caravan BBQ slide system is designed to provide safe, convenient access to your BBQ or outdoor appliances in caravans, RVs, and mobile kitchens. Built from durable galvanised metal, it delivers reliable support for compact through to larger BBQ setups, with flexible mounting options to suit your available space. The slide allows your BBQ to be mounted either Front to Rear or Sideways, making it adaptable to different vehicle layouts. Smaller sizes feature a single lock-in position for secure storage, while the 800mm model includes three lock positions for added flexibility. Ideal for drawer-style installations, this slide system helps maximise usable space while keeping your BBQ stable during travel.
Features
ā¢ Galvanised steel construction for durability in mobile environments
ā¢ Available in 500mm, 600mm, and 800mm slide lengths
ā¢ Supports up to 45kg on 500mm and 600mm models, up to 110kg on 800mm model
ā¢ Mounting options allow BBQ installation Front to Rear or Sideways
ā¢ Single lock-in position on 500mm and 600mm slides
ā¢ Three lock-in positions on 800mm slide (In, Mid-way, Out)
ā¢ Designed for caravans, RVs, and mobile kitchens
ā¢ Smooth slide operation for easy BBQ access and storage
Specifications
General
ā¢ Material: Galvanised metal
ā¢ Mounting options: Front to Rear or Sideways
ā¢ Application: Caravan, RV, mobile kitchen BBQ installations
500mm Slide
ā¢ Maximum load: 45kg
ā¢ Dimensions: 495mm(W) x 1050mm(L) x 45mm(H)
ā¢ Weight: 6kg
ā¢ Lock positions: 1 (In)
600mm Slide
ā¢ Maximum load: 45kg
ā¢ Dimensions: 495mm(W) x 1230mm(L) x 55mm(H)
ā¢ Weight: 7.4kg
ā¢ Lock positions: 1 (In)
800mm Slide
ā¢ Maximum load: 110kg
ā¢ Dimensions: 495mm(W) x 1620mm(L) x 60mm(H)
ā¢ Weight: 9.3kg
ā¢ Lock positions: 3 (In, Mid-way, Out)
Warranty Information
Warranty : 1 Year
